Mobile clay pigeon trap performance, built for full control
The Acorn Navigator AC320 ABT Quad is a fully mobile clay pigeon trap system, designed to give you complete control over your target presentation across a wide range of shooting applications. Whether you are setting up for sporting practice, simulated game, club use or a more bespoke layout, the Quad system allows you to position, adjust and refine your targets with ease.
Mounted on a quad trailer and paired with the Navigator control system, it combines proven trap performance with the flexibility to adapt to different ground, different layouts and different shooting requirements. It is a system designed not just to work in one position, but to make the most of the space you have available.
Why choose the Navigator AC320 ABT Quad?
-
Mobile clay pigeon trap system for flexible ground use
-
Combines oscillation and vertical lift for varied target presentations
-
Controlled via Navigator radio for precise adjustment
-
Designed and manufactured in the UK for long-term reliability
See The Full Description Request A Quote
A clay pigeon trap system that moves with you
Not every ground is the same, and not every layout stays fixed. The Navigator AC320 ABT Quad is designed to give you the freedom to move your setup and adapt to the space in front of you.
The quad trailer allows the system to be repositioned easily, while the built-in movement gives you the ability to adjust targets without constantly relocating the machine. This makes it suitable for customers who want flexibility without compromising on performance.
Full control over your target presentation
The combination of oscillation and vertical lift allows you to create a wide range of target presentations from a single system.
You can vary height, angle and direction to produce targets that are less predictable and more engaging to shoot. Paired with the Navigator radio, these adjustments can be made with precision, giving you full control over how your layout performs.
Built for consistent performance
At its core, the system uses the proven AutoClay 320, delivering strong and consistent throwing performance.
Capable of throwing targets to distances of around 130 metres, it provides reliable, repeatable target delivery across a wide range of shooting disciplines. This consistency is key, whether you are setting up a practice stand or creating a more varied shooting experience.
Suitable for a wide range of applications
The Navigator AC320 ABT Quad works well across a broad range of shooting uses, including:
- Sporting layouts
- Club and ground use
- Simulated game setups
- Practice and training environments
- Mobile and adaptable shooting layouts
Because of its mobility and control, it is particularly suited to setups where layouts change regularly or where you want to make full use of the available ground.
Designed and manufactured in the UK
Like all Acorn products, the Navigator AC320 ABT Quad is designed and manufactured by us here in the UK. That means the people behind the product understand both the engineering and the shooting application.
We build equipment that works in the real world — reliable, practical and built for ongoing use.
Speak to Acorn
If you would like to discuss the Navigator AC320 ABT Quad, call us to talk through your requirements or use our contact form and we will come back to you.
Full Specification
System & Configuration
- System type: Mobile clay pigeon trap system
- Trap model: AutoClay 320
- Mounting: Quad trailer with integrated movement system
- Configuration: Single unit or multiple units linked together
- Installation: Fully mobile, towable setup
- Build: Heavy-duty construction for regular use
Target Presentation
- Movement: Left-to-right oscillation
- Vertical adjustment: Integrated lift for height variation
- Presentation range: Wide range of angles, heights and directions
- Adjustability: Fine control via Navigator radio system
Performance
- Throwing distance: Up to approximately 130 metres (setup dependent)
- Target consistency: Clean, repeatable target delivery
- Operation: Smooth, reliable cycling for regular use
Control & Operation
- Control system: Acorn Navigator radio
- Functionality: Control of oscillation and vertical lift
- Adjustment: Precise positioning and target setup
- Multi-trap operation: Units can be linked together (daisy chain)
- User operation: Suitable for single-operator use
Mobility
- Trailer type: Quad trailer configuration
- Movement: Designed for easy repositioning across ground
- Deployment: Quick setup and relocation between positions
- Ground use: Suitable for varied terrain and changing layouts
Build & Durability
- Construction: Designed for outdoor and regular use
- Finish: Durable protective coating
- Engineering: Designed and manufactured in the UK
- Maintenance: Straightforward access for servicing
Applications
- Sporting layouts
- Simulated game setups
- Clubs and shooting grounds
- Practice and training environments
- Mobile and adaptable shooting layouts
Optional Configuration
- Multi-unit setups using daisy chain linking
- Integration into larger simulated game layouts
- Bespoke system design based on ground and requirements
Notes
- Throwing performance depends on setup, spring configuration and installation
- Multiple units can be deployed across a ground to increase variation and depth
Full Description
A Fully Mobile Clay Pigeon Trap System
The Navigator AC320 ABT Quad is a fully mobile clay pigeon trap system, designed to give you greater control over how and where you present your targets. Mounted on a quad trailer, it allows you to position your trap easily and adapt your setup to suit different ground, layouts and shooting requirements.
It is built for situations where flexibility matters, giving you the ability to move, adjust and refine your target presentation without being restricted to a fixed position.
Full Control Over Target Presentation
One of the key strengths of the Navigator AC320 ABT Quad is the level of control it offers.
With both left-to-right oscillation and vertical lift built into the system, you can create a wide range of target presentations from a single clay pigeon trap. This includes adjusting height, angle and direction to produce targets that are less predictable and more engaging to shoot.
Paired with the Navigator radio, these adjustments can be made with precision, allowing you to refine your setup without constantly repositioning the machine.
Designed to Work Across the Ground
The quad trailer setup allows the system to be moved and repositioned with ease, making it well suited to grounds where layouts change regularly or where different areas of land are used throughout the season.
It gives you the freedom to respond to the ground in front of you, rather than being limited by fixed installations.
Expandable for Larger Setups
The Navigator AC320 ABT Quad is not limited to single-unit use. Where required, multiple systems can be linked together using a daisy chain setup, allowing them to operate as part of a wider layout.
This makes it possible to position traps across the ground, move them quickly into place and build more complex shooting setups with greater depth and variation. Systems can be dropped into position and linked together, giving you a flexible way to expand without permanent infrastructure.
Consistent, Proven Performance
At its core, the system uses the AutoClay 320 clay pigeon trap, delivering strong and consistent throwing performance.
Capable of throwing targets to distances of around 130 metres, it provides reliable, repeatable target delivery across a wide range of shooting disciplines. This consistency is key for both practice and more structured shooting setups.
Built for Regular Use
The Navigator AC320 ABT Quad is designed for ongoing, practical use. The construction is robust, the system is straightforward to operate, and it is built to perform reliably in real-world conditions.
It is well suited to shooting grounds, clubs and individuals who require equipment that can handle regular use without compromise.
Designed and Manufactured in the UK
Like all Acorn systems, the Navigator AC320 ABT Quad is designed and manufactured by us here in the UK. It reflects a practical, engineering-led approach, built by people who understand how clay pigeon traps are used in the field.
A Flexible, Scalable Shooting Solution
If you are looking for a clay pigeon trap system that offers mobility, precise control and the ability to expand into larger layouts, the Navigator AC320 ABT Quad provides a highly capable and adaptable solution.
Optional Extras
- Trap Cover
- Midi 90 insert
- Mini 70 insert
- Mini 60 insert
- 50mm Tow Ball
Videos
Photo Gallery
FAQ
What is the Navigator AC320 ABT Quad?
The Navigator AC320 ABT Quad is a mobile clay pigeon trap system combining the AutoClay 320 with a quad trailer, integrated movement and the Navigator radio control system. It is designed to give full flexibility over target presentation and positioning.
Should I choose the Quad or the Osc version?
It depends on how you want to use the system.
The Navigator AC320 ABT Osc is well suited to setups where the trap will stay in a fixed position but you still want controlled left-to-right movement for varied target presentations. It is a good option for established stands or locations where the layout does not need to change regularly.
The Navigator AC320 ABT Quad offers a higher level of flexibility. In addition to oscillation, it includes vertical lift and is mounted on a quad trailer, allowing you to move the system across the ground and adjust both position and target presentation.
If you are looking for a more adaptable setup that can be repositioned and developed over time — or used across different areas of ground — the Quad version gives you more scope to vary your targets and make full use of your space.
What makes the Quad version different?
The Quad version provides both mobility and full movement of the trap. With left-to-right oscillation and vertical lift built in, it allows you to create a much wider range of target presentations compared to a fixed or non-mobile setup.
Can I move the system easily?
Yes, the quad trailer allows the system to be moved and repositioned across different areas of ground. This makes it ideal for changing layouts or making better use of the terrain available.
What does the Navigator radio do?
The Navigator is Acorn’s wireless control system, allowing you to control functions such as oscillation and movement remotely. It gives you precise control over your target presentation without needing to adjust the machine manually.
Can I adjust the height of the targets?
Yes, the system includes vertical lift, allowing you to change the height of the trap and create higher or more varied target presentations.
Can multiple Quad systems be used together?
Yes, multiple Navigator AC320 ABT Quad systems can be linked together using a daisy chain setup. This allows you to operate several traps as part of a wider layout, adding more depth and variation across the ground.
Why would I use more than one unit?
Using multiple units allows you to spread traps across the ground, introduce different target angles and create more varied and engaging shooting layouts. It is particularly useful for simulated game setups or larger shooting areas.
How far will the trap throw targets?
The system is capable of throwing targets to distances of around 130 metres, depending on setup.
Is this suitable for simulated game shooting?
Yes, the Navigator AC320 ABT Quad is well suited to simulated game setups, particularly where varied and adjustable target presentations are required.
Is it suitable for regular use?
Yes, it is designed for regular operation and is well suited to shooting grounds, clubs and individuals who need reliable equipment for ongoing use.
Is the system supplied ready to use?
Yes, the system is supplied with batteries, allowing it to be used without needing to source additional power equipment.
Where is it manufactured?
All Acorn systems are designed and manufactured in the UK.
Can I discuss a bespoke setup?
Yes. If you have a particular layout or target presentation in mind, Acorn can help design a system tailored to your requirements.
